| Catalogue No. |
PFP/IB/08 |
| Type of Ex-Protection |
AS PER IS / IEC-60079-1:2007 |
| Zone Classification |
Zone 1 & Zone 2 |
| Gas Group |
Gas Group I, IIA, IIB |
| Ingress IP Protection |
IP-65 IS / IEC60529-2001 |
| Material of Contraction |
Die Cast Aluminum Alloy LM6 |
| Glass Window |
1 No. 100 X 50 mm Glass Window |
| Contact Element |
Electronics PCB with 4-5 Nos. Key / 4-5 Nos. 10A No. Elements |
| Push |
4-5 Nos. Green Push |
| Terminal |
12 Way Clip on Rail or Strip Type |
| Paint |
Epoxy Polyester Powder Coating |
| Earthling |
Internal: 01 No. & External: 2 Nos. |
| Cable Entry |
03-05 Nos. for M20 (3/4” ET) |
| Hardware |
Stainless Steel |
