| Catalogue No. |
PFP/PBS/09 |
| Type of Ex-Protection |
AS PER IS / IEC-60079-1:2007 |
| Zone Classification |
Zone 1 & Zone 2 |
| Gas Group |
Gas Group I, IIA, IIB |
| Ingress IP Protection |
IP-65 IS / IEC60529-2001 |
| Material of Contraction |
High Pressure Die Cast Aluminum Alloy LM6 |
| Paint |
Epoxy Polyester Powder Coating |
| Earthling |
Internal: 01 No. & External: 2 Nos. |
| Cable Entry |
02 Nos. for M20 (3/4” ET) |
| Hardware |
Stainless Steel |
| Green Push Button |
START with 1 NO Contact element for 10 AMP |
| Red Push Button |
STOP Mushroom Head Pad Lock with 1 NC Contact 10AMP |
