| Type of Ex-Protection |
AS PER IS / IEC-60079-1:2007 |
| Zone Classification |
Zone 1 & Zone 2 |
| Gas Group |
Gas Group I, IIA, IIB |
| Ingress IP Protection |
IP-65 IS / IEC60529-2001 |
| Material of Contraction |
Die Cast Aluminum Alloy LM6 |
| Wire Guard |
M.S. White Powder Coates |
| Rating |
100W GLS, 60W GLS, 18W CFL, 9W-12W LED |
| Lamp Holder |
Enclosed Break Porcelin E-27 |
| Glass |
TYPE "A" Toughened AS PER IS:2206 / 84 (PART-I) |
| Paint |
Epoxy Polyester Powder Coating |
| Earthling |
Internal: 01 No. & External: 2 Nos. |
| Cable Entry |
02 Nos. for M20 (3/4” ET) |
| Hardware |
Stainless Steel |
